Kubernetes Demystified Part 2 - Organisation

#

In part 1 of the Kubernetes Demystified series, I covered quite a lot, getting straight into getting your hands dirty creating and running apps. I wanted to start off this way, to show that Kubernetes doesn’t have to be intimidating if you’re used to Docker and running containers.

In this follow up, I’d like to take a step back, a little more chill, and talk about the features Kubernetes provides for you to organise your resources.

Namespaces

#

In Kubernetes, all resources are assigned to a Namespace. In part 1, we didn’t interact with namespaces at all, so everything was done in the default namespace.

Namespaces can be used however it makes sense to you to organise your workloads. I tend to have one Namespace per app. This might contain the application itself, database, the landing page, the docs, and a supporting service like an analytics service. Simpler application Namespaces that are entirely separate might just contain a single deployment, like the Namespace for this website. In a fancy multi-environment setup, you might use staging-app, dev-app or main-app Namespaces.

You can create Namespaces imperatively on the command line:

kubectl create namespace super-app

Or declaratively using Kube YAML:

apiVersion: v1
kind: Namespace
metadata:
  name: super-app

If you put the Namespace declaration at the top of your application’s YAML, it will be created first, and you can put all your resources into it.

apiVersion: v1
kind: Namespace
metadata:
  name: super-app
---
apiVersion: apps/v1
kind: Deployment
metadata:
    name: my-app
    namespace: super-app
spec:
    replicas: 3
    [...]

When using Kubectl or other command line tools designed to interact with Kubernetes, the Namespace can be specified using the -n or --namespace flag.

kubectl -n super-app get pods
kubectl -n super-app describe deployment my-app

I like to put the -n flag at the start, to make it more ergonomic to change my next command.

You can also list all Namespaces just like any other resource:

kubectl get namespaces

Finally, there are a handful of resources that are not namespace-scoped in a Kubernetes cluster. These are called cluster scoped resources. The most common type of these you’ll be interacting with are Persistent Volumes, though the PersistentVolumeClaims that bind them to your applications are namespaced.

If you specify a namespace while interacting with these resources, no error will be thrown, so don’t worry too much.

kubectl get persistentvolumes # Get the cluster-scoped resource
kubectl -n foobar get persistentvolumes # Output is identical if foobar exists

Labels

#

Both Labels and Annotations are arbitrary key-value pairs you can set on any Kubernetes resource, but they serve slightly different purposes.

Labels should uniquely identify the resource. For example, you might use these labels:

apiVersion: v1
kind: Pod
metadata:
  name: my-app-pod
  labels:
    app: my-app
    environment: production

You can then use these labels to select resources. For example, you might want to get all the Pods for your app:

kubectl -n super-app get pods -l app=my-app

Or follow the logs for all the replicas of your app:

kubectl -n super-app logs -f -l app=my-app

Annotations

#

Annotations look and feel similar to Labels, but they should be used for things that don’t identify your app.

apiVersion: v1
kind: Pod
metadata:
  name: my-app-pod
  annotations:
    kubernetes.io/description: "Primary frontend for my-app"
    team.example.com/owner: "frontend-team"

Annotations are often used by controllers and Kubernetes addons (to be covered in part 4) to hold configuration.

Ingress - Tying it All Together

#

To tie all of these concepts together, I’m going to introduce one more resource we didn’t cover in part 1. The Ingress resource.

An Ingress allows you to send external traffic to one or more of the Services running in your cluster. Let’s look at a full example:

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: web-frontend-ingress
  namespace: production
  labels:
    app.kubernetes.io/name: web-frontend
    app.kubernetes.io/environment: production
  annotations:
    # Forces all HTTP traffic to redirect to HTTPS
    nginx.ingress.kubernetes.io/ssl-redirect: "true"
    # Basic rate limiting for the root path
    nginx.ingress.kubernetes.io/limit-rps: "10"
spec:
  ingressClassName: nginx
  rules:
  - host: app.example.com
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: web-frontend-service
            port:
              number: 80

Here we create an Ingress object in the production namespace, with some of the Kubernetes recommended labels set. This Ingress configuration sends all traffic for app.example.com to the service web-frontend-service.

Homework

#

Set up a Kubernetes Ingress object for the Nginx production setup we configured in Part 1. The example above gives you most of the YAML needed.

Most Kubernetes environments come with a Kubernetes Ingress Controller (more about controllers in a future instalment). If not Nginx, it might be Traefik or Envoy. You can find out by running kubectl get ingressclass, and searching the right configuration for yours.

One Last Tip

#

You’re going to be running kubectl a lot. I like to set up an alias in my shell so I can just use k.

alias k=kubectl

You can also add this line to your .bashrc (or whatever the equivalent for your shell is), to make the alias permanent. You’ll also want to make sure that Kubectl’s autocomplete is loaded in there too. Here’s my .zshrc for Mac and some Linuxes:

# Load the completion system (prevents error)
autoload -Uz compinit
compinit

source <(kubectl completion zsh)

# alias Kubectl and set up completion
alias k=kubectl
compdef _kubectl k

Also, many resources in Kubernetes have “shorthand” names you can use. With the alias above set up, the following are all equivalents:

kubectl get namespaces
k get ns

kubectl get persistentvolumeclaims
k get pvc

kubectl describe service wordpress
k describe svc wordpress

Conclusion

#

I’ve shown you some tips and tricks today for how to get Kubernetes to work more ergonomically for you, and how to be tidy and organise your resources so other admins will know what’s going on.

In the next part, I’m going to cover configuring your app and using secrets, then in part 4 I will cover controllers and addons, which we touched on briefly here today.
